ABB HT568964 - Table 42 Tightening Torques

Operation Manual / 4 Product description / A100-M axial
8
Disassembly and assembly
Page 91 /
113
© Copyright 2016 ABB. All rights reserved.
HZTL4033_EN
Revision A
July 2016
Thread sizes and tightening torques [Nm]
Position
Part number
A170-M
A175-M
01 82005 M22x1.5
80
M22x1.5
80
02 77015 M5
6
M6
10
03
61036
M22
60
M24
80
04 61037 M22
415
M24
490
05 61090 M22
50
M24
50
06 61059 / 42128 M22
415
M24
490
07 61069 M14
130
M16
200
08 63001 M14
170
M18
240
09
56014
M10
50
M10
50
10 61009 M18
280
1)
M20
380
1)
11 57005 M14
130
M16
200
12 42059 M16
200
M16
200
13 72011 M20
580
M24
1000
14 72027 M18
170
M20
220
15 72026 M18
40
M20
50
16 25013 M8
20
M10
40
17 86505 M18x1.5
150
M18x1.5
150
Table 42: Tightening torques
1) Tighten screws (61009) crosswise in four steps (see Table 43).
