Oil exchange equipment
The following table specifies the recommended equipment for oil exchange.
NoteArt. no.Description
Includes:
• Vacuum pump with regulator,
hose and coupling
• Couplings and adapters
• Pump (manual) with hose and
coupling
• Graduated measuring glass
• Oil gun
• User instructions.
3HAC021745-001
Oil exchange equipment
Basic tools
The following table specifies the tools in the basic toolkit that are used for the
current robot model. This toolkit is necessary primarily when removing and refitting
the motors.
The tools are also listed directly in the instructions.
Art. no.QtyDescription
3HAC15521-12Guide pins M10 x 100
3HAC15521-22Guide pins M10 x 150
3HAC14459-11Lifting tool, motor ax 1
3HAC15534-11Lifting tool, motor ax 2, 3
Fits motors axes 1, 2 and 3.Removal tool, motor M12x
3HAC17105-11Rotation tool
3HAC12342-11Bits extension
-1Standard toolkit (content described in sec-
tion Standard tools on page 347)
Lifting tools
The following table specifies the lifting tools required during several of the service
procedures. The tools may be ordered separately and are also specified directly
in concerned instructions in the Product manual, procedures.
Article no.QtyDescription
3HAC023154-001Lifting tool, tilt house
3HAC15534-1Lifting tool, motor
3HAC023308-001Lifting tool, frame
3HAC15607-1Lifting tool, complete robot
3HAC023098-001Lifting tool, parallel arm
3HAC14406-1Lifting tool, turning device gearbox ax.1
3HAC14868-1Lifting tool, base
Continues on next page
Product manual - IRB 660 349
3HAC025755-001 Revision: W
© Copyright 2006-2020 ABB. All rights reserved.
7 Reference information
7.7 Special tools
Continued
