FEP630, FEH630 ELECTROMAGNETIC FLOWMETER | OI/FEP630/FEH630-EN REV. D 97
Menu: Diagnostics
Menu / parameter Description
Diagnostics
...Maintenance control Selection of submenu ‘...Maintenance control’ using .
...Diagnosis Control Selection of submenu ‘...Diagnosis Control’ using .
...Diagnosis Values Selection of submenu ‘...Diagnosis Values’ using .
......Simulation Mode Selection of submenu ‘......Simulation Mode’ using .
...Output Readings Selection of submenu ‘...Output Readings’ using .
Diagnostics / ...Maintenance control
Preset Maint. cycle Setting the service interval (0 to 9999 hours).
After the service interval has expired, the corresponding error message ‘M026.004’ (Service interval has been reached) is
set. The setting ‘0’ deactivates the maintenance interval.
Maint. Remain. Time Remaining service interval time until setting of error message ‘M026.004.’
Start New Cycle Resetting of the maintenance interval. The service interval is reset to the value set in ‘Preset Maint. cycle’.
Diagnostics / ...Diagnosis Control
...Diagnosis Tfe Selection of submenu ‘...Diagnosis Tfe’ using .
...Empty Pipe Detector Selection of submenu ‘...Empty Pipe Detector’ using .
...Diagnosis Coil* Selection of submenu ‘...Diagnosis Coil’ using .
...Diagnosis Gas Bub.* Selection of submenu ‘...Diagnosis Gas Bub.’ using .
...Diagnosis Conductiv* Selection of submenu ‘...Diagnosis Conductiv’ using .
...Diagnosis SIL** Selection of submenu ‘...Diagnosis SIL’ using .
...Noise Check Selection of submenu ‘...Noise Check’ using .
...Fingerprints Selection of submenu ‘...Fingerprints’ using .
Diagnosis Interval Set the time span between the performance of each individual diagnosis.
Default setting: 5 s.
* The menu is only available if the Expert Diagnosis function is activated. See also the ‘Device Setup\...Transmitter\...Feature Settings’ menu.
** Menu only available if SIL diagnostic function is activated. See also the ‘Device Setup\...Transmitter\...Feature Settings’ menu.
