11.7.3 Setting guidelines
The function does not have any parameters available in the local HMI or Protection and
Control IED Manager (PCM600).
11.8 Integer to boolean 16 conversion with logic node
representation IB16FCVB
11.8.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Integer to boolean 16 conversion with
logic node representation
IB16FCVB - -
11.8.2 Application
Integer to boolean 16 conversion with logic node representation function (IB16FCVB) is
used to transform an integer into a set of 16 binary (logical) signals. IB16FCVB function
can receive an integer from a station computer – for example, over IEC 61850–8–1. These
functions are very useful when the user wants to generate logical commands (for selector
switches or voltage controllers) by inputting an integer number. IB16FCVB function has
a logical node mapping in IEC 61850.
11.8.3 Settings
The function does not have any parameters available in the local HMI or Protection and
Control IED Manager (PCM600)
11.9 Elapsed time integrator with limit transgression and
overflow supervision TEIGGIO
11.9.1 Identification
Function Description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2 device
number
Elapsed time integrator TEIGGIO - -
Section 11 1MRK 511 286-UUS A
Logic
280
Application manual
