ABB REF615 F - Monitored Data

Parameter Values (Range) Unit Step Default Description
Control model 0=status-only
1=direct-with-
normal-security
4=sbo-with-
enhanced-security
4=sbo-with-
enhanced-security
Select control model
Adaptive pulse 0=False
1=True
1=True Stop in right position
Event delay 0...10000 ms 1 100 Event delay of the intermediate position
Operation timeout 10...60000 ms 500 Timeout for negative termination
Table 596: ESXSWI Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation mode on/off
Select timeout 10000...300000 ms 10000 60000 Select timeout in ms
Pulse length 10...60000 ms 1 100 Open and close pulse length
Operation counter 0...10000 0 Breaker operation cycles
Control model 0=status-only
1=direct-with-
normal-security
4=sbo-with-
enhanced-security
4=sbo-with-
enhanced-security
Select control model
Adaptive pulse 0=False
1=True
1=True Stop in right position
Event delay 0...10000 ms 1 100 Event delay of the intermediate position
Operation timeout 10...60000 ms 500 Timeout for negative termination
9.1.8 Monitored data
Table 597: CBXCBR Monitored data
Name
Type Values (Range) Unit Description
POSITION Dbpos 0=intermediate
1=open
2=closed
3=faulty
Apparatus position
indication
Table 598: DCXSWI Monitored data
Name
Type Values (Range) Unit Description
POSITION Dbpos 0=intermediate
1=open
2=closed
3=faulty
Apparatus position
indication
