Name Type Description
PARALLEL BOOLEAN Parallel or single operation
AUTO BOOLEAN Auto/Manual indication
TIMER_ON BOOLEAN Timer on
BLKD_I_LOD BOOLEAN Indication of over current blocking
BLKD_U_UN BOOLEAN Indication of under voltage blocking
RNBK_U_OV BOOLEAN Indication of raise voltage runback
BLKD_I_CIR BOOLEAN Indication of high circulating current blocking
BLKD_LTCBLK BOOLEAN Indication of external blocking
9.5.17 Settings
Table 638: OLATCC Group settings
Parameter Values (Range) Unit Step Default Description
Auto parallel mode 2=Auto master
3=Auto follower
5=NRP
7=MCC
2=Auto master Parallel mode selection
Band center voltage 0.000...2.000 xUn 0.001 1.000 Band center voltage Us
Line drop V Ris 0.0...25.0 % 0.1 0.0 Resistive line-drop compensation factor
Line drop V React 0.0...25.0 % 0.1 0.0 Reactive line-drop compensation factor
Band reduction 0.00...9.00 %Un 0.01 0.00 Step size for reduce set voltage (RSV)
Stability factor 0.0...70.0 % 0.1 0.0 Stability factor in parallel operation
Load phase angle -89...89 deg 1 0 Load phase-shift, used only with the
negative reactance principle
Control delay time 1 1000...300000 ms 100 60000 Control delay time for the first control
pulse
Control delay time 2 1000...300000 ms 100 30000 Control delay time for the following
control pulses
Table 639: OLATCC Non group settings
Parameter
Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
Operation mode 1=Manual
2=Auto single
3=Auto parallel
4=Input control
4=Input control The operation mode
Custom Man blocking 1=Custom disabled
2=OC
3=UV
4=OC, UV
5=EXT
6=OC, EXT
7=UV, EXT
8=OC, UV, EXT
2=OC Customized manual blocking
Table continues on next page
1YHT530004D05 D Section 9
Control functions
615 series 759
Technical Manual
