ABB REF615 F User Manual

1.3 Product documentation
1.3.1 Product documentation set
Planning & purchase Engineering Installation Commissioning Operation Maintenance Decommissioning, deinstallation & disposal
Quick start guide
Quick installation guide
Brochure
Product guide
Operation manual
Installation manual
Connection diagram
Engineering manual
Technical manual
Application manual
Communication protocol manual
IEC 61850 Engineering guide
Point list manual
c
c
GUID-12DC16B2-2DC1-48DF-8734-0C8B7116124C V1 EN
Figure 1: The intended use of documents during the product life cycle
Product series- and product-specific manuals can be downloaded
from the ABB Website http://www.abb.com/relion.
1.3.2 Document revision history
Document revision/date
Product version History
A/2009-09-29 2.0 First release
B/2010-07-02 3.0 Content updated
C/2014-05-14 4.1 Content updated to correspond to the
product series version
D/2014-09-12 4.1.1 Content updated to correspond to the
product series version
Download the latest documents from the ABB Website
http://www.abb.com/substationautomation.
Section 1 1YHT530004D05 D
Introduction
26 615 series
Technical Manual

ABB REF615 F Specifications

General

Type	Feeder Protection Relay
Nominal Frequency	50/60 Hz
Rated Current	1 A / 5 A
Protection Functions	Overcurrent, Earth Fault, Under/Over Voltage
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Mounting	Flush mounting
Ingress Protection	IP54 (front), IP20
Operating Temperature Range	-25 to +55 °C
