ABB REF615 F - Monitored Data

4.1.3.10 Monitored data
Table 207: DPHLPDOC Monitored data
Name Type Values (Range) Unit Description
START_DUR FLOAT32 0.00...100.00 % Ratio of start time /
operate time
FAULT_DIR Enum 0=unknown
1=forward
2=backward
3=both
Detected fault direction
DIRECTION Enum 0=unknown
1=forward
2=backward
3=both
Direction information
DIR_A Enum 0=unknown
1=forward
2=backward
3=both
Direction phase A
DIR_B Enum 0=unknown
1=forward
2=backward
3=both
Direction phase B
DIR_C Enum 0=unknown
1=forward
2=backward
3=both
Direction phase C
ANGLE_A FLOAT32 -180.00...180.00 deg Calculated angle
difference, Phase A
ANGLE_B FLOAT32 -180.00...180.00 deg Calculated angle
difference, Phase B
ANGLE_C FLOAT32 -180.00...180.00 deg Calculated angle
difference, Phase C
DPHLPDOC Enum 1=on
2=blocked
3=test
4=test/blocked
5=off
Status
Table 208: DPHHPDOC Monitored data
Name
Type Values (Range) Unit Description
START_DUR FLOAT32 0.00...100.00 % Ratio of start time /
operate time
FAULT_DIR Enum 0=unknown
1=forward
2=backward
3=both
Detected fault direction
DIRECTION Enum 0=unknown
1=forward
2=backward
3=both
Direction information
Table continues on next page
