Name Type Default Description
IN6 BOOLEAN 0=False Input 6 status
IN7 BOOLEAN 0=False Input 7 status
IN8 BOOLEAN 0=False Input 8 status
Table 130: TOFGAPC Output signals
Name Type Description
Q1 BOOLEAN Output 1 status
Q2 BOOLEAN Output 2 status
Q3 BOOLEAN Output 3 status
Q4 BOOLEAN Output 4 status
Q5 BOOLEAN Output 5 status
Q6 BOOLEAN Output 6 status
Q7 BOOLEAN Output 7 status
Q8 BOOLEAN Output 8 status
3.14.4.4 Settings
Table 131: TOFGAPC Non group settings
Parameter
Values (Range) Unit Step Default Description
Off delay time 1 0...3600000 ms 10 0 Off delay time
Off delay time 2 0...3600000 ms 10 0 Off delay time
Off delay time 3 0...3600000 ms 10 0 Off delay time
Off delay time 4 0...3600000 ms 10 0 Off delay time
Off delay time 5 0...3600000 ms 10 0 Off delay time
Off delay time 6 0...3600000 ms 10 0 Off delay time
Off delay time 7 0...3600000 ms 10 0 Off delay time
Off delay time 8 0...3600000 ms 10 0 Off delay time
3.14.4.5 Technical data
Table 132: TOFGAPC Technical data
Characteristic
Value
Operate time accuracy ±1.0% of the set value or ±20 ms
Section 3 1YHT530004D05 D
Basic functions
124 615 series
Technical Manual
