Channel ID text Level trigger mode
15 PHPTOV2 - start Positive or Rising
16 PHPTOV3 - start Positive or Rising
17 PSPTUV1 - start Positive or Rising
18 NSPTOV1 - start Positive or Rising
19 PHPTUV1 - start Positive or Rising
20 PHPTUV2 - start Positive or Rising
21 PHPTUV3 - start Positive or Rising
22 ROVPTOV1 - start Positive or Rising
23 ROVPTOV2 - start Positive or Rising
24 ROVPTOV3 - start Positive or Rising
25 CCBRBRF1 - trret Level trigger off
26 CCBRBRF1 - trbu Level trigger off
27 PHIPTOC1 - operate Level trigger off
DPHHPDOC1 - operate
DPHLPDOC1 - operate
DPHLPDOC2 - operate
28 NSPTOC1 - operate Level trigger off
NSPTOC2 - operate
29 DEFHPDEF1 - operate Level trigger off
DEFLPDEF1 - operate
DEFLPDEF2 - operate
30 INTRPTEF1 - operate Level trigger off
31 EFHPTOC1 - operate Level trigger off
32 PDNSPTOC1 - operate Level trigger off
33 INRPHAR1 - blk2h Level trigger off
34 T1PTTR1 - operate Level trigger off
35 PHPTOV1 - operate Level trigger off
PHPTOV2 - operate
PHPTOV3 - operate
36 PHPTUV1 - operate Level trigger off
PHPTUV2 - operate
PHPTUV3 - operate
37 ROVPTOV1 - operate Level trigger off
ROVPTOV2 - operate
ROVPTOV3 - operate
PSPTUV1 - operate
NSPTOV1 - operate
38 SEQSPVC1 - fusef 3ph Level trigger off
39 SEQSPVC1 - fusef u Level trigger off
Table continues on next page
Section 3 1MRS756378 S
REF615 standard configurations
