Channel ID text Level trigger mode
15 PHPTOV1 - start Positive or Rising
16 PHPTOV2 - start Positive or Rising
17 PHPTUV1 - start Positive or Rising
18 PHPTUV2 - start Positive or Rising
19 ROVPTOV1 - start Positive or Rising
20 ROVPTOV2 - start Positive or Rising
21 FRPFRQ1 - start Positive or Rising
22 FRPFRQ2 - start Positive or Rising
23 FRPFRQ3 - start Positive or Rising
24 HREFPDIF1 - start Positive or Rising
25 CCBRBRF1 - trret Level trigger off
26 CCBRBRF1 - trbu Level trigger off
27 PHIPTOC1 - operate Level trigger off
PHHPTOC1 - operate
PHLPTOC1 - operate
28 DPHLPDOC1 - operate Level trigger off
DPHHPDOC1 - operate
29 NSPTOC1 - operate Level trigger off
NSPTOC2 - operate
30 EFLPTOC1 - operate Level trigger off
EFLPTOC2 - operate
EFHPTOC1 - operate
EFIPTOC1 - operate
31 DEFLPDEF1 - operate Level trigger off
DEFHPDEF1 - operate
32 T1PTTR1 - operate Level trigger off
33 INRPHAR1 - blk2h Level trigger off
34 PHPTOV1 - operate Level trigger off
PHPTOV2 - operate
35 PHPTUV1 - operate Level trigger off
PHPTUV2 - operate
36 ROVPTOV1 - operate Level trigger off
ROVPTOV2 - operate
37 FRPFRQ1 - operate Level trigger off
FRPFRQ2 - operate
FRPFRQ3 - operate
38 SEQSPVC1 - fusef3ph Level trigger off
39 SEQSPVC1 - fusefu Level trigger off
40 CCSPVC1 - fail Level trigger off
Table continues on next page
Section 3 1MRS756378 S
REF615 standard configurations
294 REF615
Application Manual
