Terminal Description
X110:4 BI4, +
X110:5 BI4, -
X110:6 BI5, +
X110:10 BI5, -
X110:7 BI6, +
X110:10 BI6, -
X110:8 BI7, +
X110:10 BI7, -
X110:9 BI8, +
X110:10 BI8, -
Binary inputs of slot X120 are available with configurations C, D, E, F, H, J and N
Table 84: Binary input terminals X120-1...6
Terminal Description
X120:1 BI1, +
X120:2 BI1, -
X120:3 BI2, +
X120:2 BI2, -
X120:4 BI3, +
X120:2 BI3, -
X120:5 BI4, +
X120:6 BI4, -
Binary inputs of slot X120 are available with configurations A and B.
Table 85: Binary input terminals X120:1-4
Terminal
Description
X120:1 BI1, +
X120:2 BI1, -
X120:3 BI2, +
X120:2 BI2, -
X120:4 BI3, +
X120:2 BI3, -
Binary inputs of slot X130 are optional for configurations B and D.
Section 5 1MRS756378 S
IED physical connections
386 REF615
Application Manual
