Table 158. Analog system selection
Analog system Selection Notes and Rules
No first TRM included X0 Note: Only valid in RET670–N00
Compression terminals A Note: Only the same type of TRM
(compression or ringlug) in the
same terminal.
Ringlug terminals B
First TRM 12I 1A, 50/60Hz 1
First TRM 12I 5A, 50/60Hz 2
First TRM 9I+3U 1A, 100/220V, 50/60Hz 3
First TRM 9I+3U 5A, 100/220V, 50/60Hz 4
First TRM 5I, 1A+4I, 5A+3U, 100/220V, 50/60Hz 5
First TRM 6I+6U 1A, 100/220V, 50/60Hz 6
First TRM 6I+6U 5A, 100/220V, 50/60Hz 7
First TRM 6I 1A, 50/60Hz 8 Maximum qty=1
First TRM 6I 5A, 50/60Hz 9 Maximum qty=1
First TRM 7I+5U 1A, 100/220V, 50/60Hz 12
First TRM 7I+5U 5A, 100/220V, 50/60Hz 13
First TRM 6I, 5A + 1I, 1A + 5U, 110/220V, 50/60Hz 14
First TRM 3I, 5A + 4I, 1A + 5U, 110/220V, 50/60Hz 15
First TRM 3I, 5A + 3I, 1A + 6U, 110/220V, 50/60Hz 16
First TRM 3IM, 1A + 4IP, 1A + 5U, 110/220V, 50/60Hz 17
First TRM 3IM, 5A + 4IP, 5A + 5U, 110/220V, 50/60Hz 18
No second TRM included X0
Compression terminals A
Ringlug terminals B
Second TRM 12I 1A, 50/60Hz 1
Second TRM 12I 5A, 50/60Hz 2
Second TRM 9I+3U 1A, 100/220V, 50/60Hz 3
Second TRM 9I+3U 5A, 100/220V, 50/60Hz 4
Second TRM 5I, 1A+4I, 5A+3U, 100/220V, 50/60Hz 5
Second TRM 6I+6U 1A, 100/220V, 50/60Hz 6
Second TRM 6I+6U 5A, 100/220V, 50/60Hz 7
Second TRM 6I 1A, 50/60Hz 8 Maximum qty=1
Second TRM 6I 5A, 50/60Hz 9 Maximum qty=1
Second TRM 7I+5U 1A, 100/220V, 50/60Hz 12
Second TRM 7I+5U 5A, 100/220V, 50/60Hz 13
Second TRM 6I, 5A + 1I, 1A + 5U, 110/220V, 50/60Hz 14
Second TRM 3I, 5A + 4I, 1A + 5U, 110/220V, 50/60Hz 15
Second TRM 3I, 5A + 3I, 1A + 6U, 110/220V, 50/60Hz 16
Second TRM 3IM, 1A + 4IP, 1A + 5U, 110/220V, 50/60Hz 17
Second TRM 3IM, 5A + 4IP, 5A + 5U, 110/220V, 50/60Hz 18
Selected
Table 159. Maximum quantity of I/O modules
When ordering I/O modules, observe the maximum quantities according to tables below.
Note: Standard order of location for I/O modules is BIM-BOM-SOM-IOM-MIM from left to right as seen from the rear side of the IED, but can
also be freely placed.
Note: Maximum quantity of I/O modules depends on the type of connection terminals.
Note: When ordering I/O modules, observe the maximum quantities according to the table below
Case sizes
BIM IOM BOM/
SOM
MIM Maximum in case
1/1 x 19”, one (1) TRM 14 6 4 4 14 (max 4 BOM+SOM+MIM)
1/1 x 19”, two (2) TRM 11 6 4 4 11 (max 4 BOM+SOM+MIM)
3/4 x 19”, one (1) TRM 8 6 4 4 8 (max 4 BOM+SOM+1 MIM)
3/4 x 19”, two (2) TRM 5 5 4 4 5 (max 4 BOM+SOM+1 MIM)
1/2 x 19”, one (1) TRM 3 3 3 1 3
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 111
