Table 116. IRIG-B

Quantity Rated value

Number of channels IRIG-B 1

Number of optical channels 1

Electrical connector:

Electrical connector IRIG-B BNC

Pulse-width modulated 5 Vpp

Amplitude modulated

– low level

– high level

1-3 Vpp

3 x low level, max 9 Vpp

Supported formats IRIG-B 00x, IRIG-B 12x

Accuracy +/-10μs for IRIG-B 00x and +/-100μs for IRIG-B 12x

Input impedance 100 k ohm

Optical connector:

Optical connector IRIG-B Type ST

Type of fibre 62.5/125 μm multimode fibre

Supported formats IRIG-B 00x

Accuracy +/- 1μs

Transformer protection RET670 2.0

1MRK 504 141-BEN C

Product version: 2.0

98 ABB
