Table 161. Binary input/output module selection, continued
Binary input/output
modules
Selection Notes and Rules
SOM Static output
module, 12 outputs,
48-60 VDC
T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 T1 Note: SOM must not to be placed
in position nearest to NUM; 1/2
case slot P5, 3/4 case 1 TRM slot
P10, 3/4 case 2 TRM slot P7, 1/1
case 1 TRM slot P16, 1/1 case 2
TRM slot P13
SOM static outputs
module, 12 outputs,
110-250 VDC
T2 T2 T2 T2 T2 T2 T2 T2 T2 T2 T2 T2 T2 T2
Selected.
Table 162. Remote end serial communication selection
Remote end communication, DNP serial comm. and time synchronization modules Selection Notes and Rules
Slot position (rear view)
X312
X313
X302
X303
X322
X323
Available slots in 1/2, 3/4 and 1/1 case with 1TRM █ █ █ █ Note: Max 1 LDCM in 1/2 case
Available slots in 3/4 and 1/1 case with 2 TRM █ █ █ █ █ █ Note: Max 2 LDCM in 3/4 and 1/1
case
No remote communication board included X X X X X X
Optical short range LDCM A A A A A A Note: Max 2 LDCM (same or
different type) can be selected
Optical medium range, LDCM 1310 nm B B B B B B
Optical long range, LDCM 1550 nm C C C C C C
Galvanic X21 line data communication module E E E E E E
IRIG-B Time synchronization module F F F F F F
Galvanic RS485 communication module G G G G G G
GPS time synchronization module S S S S
Selected
Table 163. Serial communication unit for station communication selection
Serial communication unit for station communication
Selection Notes and Rules
Slot position (rear view)
X301
X311
No communication board included X X
Serial SPA/LON/DNP/IEC 60870-5-103 plastic interface A
Serial SPA/LON/DNP/IEC 60870-5-103 plastic/glass interface B
Serial SPA/LON/DNP/IEC 60870-5-103 glass interface C
Optical ethernet module, 1 channel glass D
Optical ethernet module, 2 channel glass E
Selected.
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
114 ABB
