ABB RET670 Product Guide

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
I103USRCMD Function commands user defined for
IEC 60870-5-103
1 1 1 1 1 1 1
Secondary system supervision
CCSSPVC 87 Current circuit supervision 0-5 2 3 3 5 4
FUFSPVC Fuse failure supervision 0-4 1 3 3 3 3
VDSPVC 60 Fuse failure supervision based on
voltage difference
0-4 1-G03 1-G03 1-G03 1-G03 1-G03 1-G03
Logic
SMPPTRC 94 Tripping logic 1-6 6 6 6 6 6 6
TMAGAPC Trip matrix logic 12 12 12 12 12 12 12
ALMCALH Logic for group alarm 5 5 5 5 5 5 5
WRNCALH Logic for group warning 5 5 5 5 5 5 5
INDCALH Logic for group indication 5 5 5 5 5 5 5
AND, OR, INV,
PULSETIMER,
GATE,
TIMERSET, XOR,
LLD,
SRMEMORY,
RSMEMORY
Configurable logic blocks 40-280 40-280 40-280 40-280 40-280 40-280 40-280
ANDQT, ORQT,
INVERTERQT,
XORQT,
SRMEMORYQT,
RSMEMORYQT,
TIMERSETQT,
PULSETIMERQT,
INVALIDQT,
INDCOMBSPQT,
INDEXTSPQT
Configurable logic blocks Q/T 0–1
SLGAPC,
VSGAPC, AND,
OR,
PULSETIMER,
GATE,
TIMERSET, XOR,
LLD,
SRMEMORY, INV
Extension logic package 0–1
FXDSIGN Fixed signal function block 1 1 1 1 1 1 1
B16I Boolean 16 to Integer conversion 18 18 18 18 18 18 18
BTIGAPC Boolean 16 to Integer conversion with
Logic Node representation
16 16 16 16 16 16 16
IB16 Integer to Boolean 16 conversion 18 18 18 18 18 18 18
ITBGAPC Integer to Boolean 16 conversion with
Logic Node representation
16 16 16 16 16 16 16
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
16 ABB

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
