ABB RET670 - Introduction; Introduction to the operators manual

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
TEIGAPC Elapsed time integrator with limit
transgression and overflow supervision
12 12 12 12 12 12 12
Monitoring
CVMMXN,
CMMXU,
VMMXU, CMSQI,
VMSQI, VNMMXU
Measurements 6 6 6 6 6 6 6
AISVBAS Function block for service value
presentation of secondary analog
inputs
1 1 1 1 1 1 1
EVENT Event function 20 20 20 20 20 20 20
DRPRDRE,
A1RADR,
A2RADR,
A3RADR,
A4RADR,
B1RBDR,
B2RBDR,
B3RBDR,
B4RBDR,
B5RBDR,
B6RBDR
Disturbance report 1 1 1 1 1 1 1
SPGAPC Generic communication function for
Single Point indication
64 64 64 64 64 64 64
SP16GAPC Generic communication function for
Single Point indication 16 inputs
16 16 16 16 16 16 16
MVGAPC Generic communication function for
Measured Value
24 24 24 24 24 24 24
BINSTATREP Logical signal status report 3 3 3 3 3 3 3
RANGE_XP Measured value expander block 66 66 66 66 66 66 66
SSIMG 63 Gas medium supervision 21 21 21 21 21 21 21
SSIML 71 Liquid medium supervision 3 3 3 3 3 3 3
SSCBR Circuit breaker monitoring 0-6 3-M13 2-M12 4-M14 3-M13 6-M15
I103MEAS Measurands for IEC 60870-5-103 1 1 1 1 1 1 1
I103MEASUSR Measurands user defined signals for
IEC 60870-5-103
3 3 3 3 3 3 3
I103AR Function status auto-recloser for IEC
60870-5-103
1 1 1 1 1 1 1
I103EF Function status earth-fault for IEC
60870-5-103
1 1 1 1 1 1 1
I103FLTPROT Function status fault protection for IEC
60870-5-103
1 1 1 1 1 1 1
I103IED IED status for IEC 60870-5-103 1 1 1 1 1 1 1
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 17
