IEC 61850 ANSI Function description Transformer

RET670

RET670 (A10)

RET670 (A30)

RET670 (B30)

RET670 (A40)

RET670 (B40)

RET670 (A25)

I103SUPERV Supervison status for IEC 60870-5-103 1 1 1 1 1 1 1

I103USRDEF Status for user defiend signals for IEC

60870-5-103

20 20 20 20 20 20 20

L4UFCNT Event counter with limit supervision 30 30 30 30 30 30 30

Metering

PCFCNT Pulse-counter logic 16 16 16 16 16 16 16

ETPMMTR Function for energy calculation and

demand handling

6 6 6 6 6 6 6

Transformer protection RET670 2.0

1MRK 504 141-BEN C

Product version: 2.0

18 ABB

Other manuals for ABB RET670

Questions and Answers:

Need help?

Do you have a question about the ABB RET670 and is the answer not in the manual?

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
