ABB RET670 - Mounting Alternatives

xx08000165.vsd
J
G
F
K
H
IEC08000165 V1 EN
Figure 14. Case with rear cover and 19” rack mounting kit
IEC06000182-2-en.vsd
IEC06000182 V2 EN
Figure 15. A 1/2 x 19” size IED side-by-side with RHGS6.
Case size
(mm)/(inches)
A B C D E F G H J K
6U, 1/2 x 19” 265.9/
10.47
223.7/
8.81
242.1/
9.53
255.8/
10.07
205.7/
8.10
190.5/
7.50
203.7/
8.02
- 228.6/
9.00
-
6U, 3/4 x 19” 265.9/
10.47
336.0/
13.23
242.1/
9.53
255.8/
10.07
318.0/
12.52
190.5/
7.50
316.0/
12.4
- 228.6/
9.00
-
6U, 1/1 x 19” 265.9/
10.47
448.3/
17.65
242.1/
9.53
255.8/
10.07
430.3/
16.86
190.5/
7.50
428.3/
16.86
465.1/
18.31
228.6/
9.00
482.6/19.00
The H and K dimensions are defined by the 19” rack mounting kit.
Mounting alternatives
• 19” rack mounting kit
• Flush mounting kit with cut-out dimensions:
– 1/2 case size (h) 254.3 mm/10.01” (w) 210.1 mm/8.27”
– 3/4 case size (h) 254.3 mm/10.01” (w) 322.4 mm/12.69”
– 1/1 case size (h) 254.3 mm/10.01” (w) 434.7 mm/17.11”
• Wall mounting kit
See ordering for details about available mounting alternatives.
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
42 ABB
