ABB RET670 Product Guide

Table 161. Binary input/output module selection
Binary input/output
modules
Selection Notes and Rules
Slot position (rear view)
X31 X41 X51 X61 X71 X81 X91
X101 X111 X121 X131 X141 X151 X161
Note! Max 3 positions in 1/2 rack, 8
in 3/4 rack with 1 TRM, 5 in 3/4
rack with 2 TRM, 11 in 1/1 rack
with 2 TRM and 14 in 1/1 rack with
1 TRM
1/2 Case with 1 TRM █ █ █
3/4 Case with 1 TRM █ █ █ █ █ █ █ █
3/4 Case with 2 TRM █ █ █ █ █
1/1 Case with 1 TRM █ █ █ █ █ █ █ █ █ █ █ █ █ █
1/1 Case with 2 TRM █ █ █ █ █ █ █ █ █ █ █
No board in slot X X X X X X X X X X X X X X
Binary output module 24
output relays (BOM)
X A A A A A A A A A A A A A
BIM 16 inputs, RL24-30
VDC, 50 mA
B1 B1 B1 B1 B1 B1 B1 B1 B1 B1 B1 B1 B1 B1
BIM 16 inputs, RL48-60
VDC, 50 mA
C1 C1 C1 C1 C1 C1 C1 C1 C1 C1 C1 C1 C1 C1
BIM 16 inputs,
RL110-125 VDC, 50 mA
D1 D1 D1 D1 D1 D1 D1 D1 D1 D1 D1 D1 D1 D1
BIM 16 inputs,
RL220-250 VDC, 50 mA
E1 E1 E1 E1 E1 E1 E1 E1 E1 E1 E1 E1 E1 E1
BIM 16 inputs, 220-250
VDC, 120mA
E2 E2 E2 E2 E2 E2 E2 E2 E2 E2 E2 E2 E2 E2
BIMp 16 inputs, RL24-30
VDC, 30 mA, for pulse
counting
F F F F F F F F F F F F F F
BIMp 16 inputs, RL48-60
VDC, 30 mA, for pulse
counting
G G G G G G G G G G G G G G
BIMp 16 inputs,
RL110-125 VDC, 30 mA,
for pulse counting
H H H H H H H H H H H H H H
BIM 16 inputs,
RL220-250 VDC, 30 mA,
for pulse counting
K K K K K K K K K K K K K K
IOM 8 inputs, 10+2
output, RL24-30 VDC, 50
mA
L1 L1 L1 L1 L1 L1 L1 L1 L1 L1 L1 L1 L1 L1
IOM 8 inputs, 10+2
output, RL48-60 VDC, 50
mA
M1 M1 M1 M1 M1 M1 M1 M1 M1 M1 M1 M1 M1 M1
IOM 8 inputs, 10+2
output, RL110-125 VDC,
50 mA
N1 N1 N1 N1 N1 N1 N1 N1 N1 N1 N1 N1 N1 N1
IOM 8 inputs, 10+2
output, RL220-250 VDC,
50 mA
P1 P1 P1 P1 P1 P1 P1 P1 P1 P1 P1 P1 P1 P1
IOM 8 inputs 10+2 output
relays, 220-250 VDC,
110mA
P2 P2 P2 P2 P2 P2 P2 P2 P2 P2 P2 P2 P2 P2
IOM with MOV 8 inputs,
10-2 output, 24-30 VDC,
30 mA
U U U U U U U U U U U U U U
IOM with MOV 8 inputs,
10-2 output, 48-60 VDC,
30 mA
V V V V V V V V V V V V V V
IOM with MOV 8 inputs,
10-2 output, 110-125
VDC, 30 mA
W W W W W W W W W W W W W W
IOM with MOV 8 inputs,
10-2 output, 220-250
VDC, 30 mA
Y Y Y Y Y Y Y Y Y Y Y Y Y Y
mA input module MIM 6
channels
R R R R R R R R R R R R R R
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 113

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
