ABB RET670 Product Guide

20. Connection diagrams
Connection diagrams
The connection diagrams are delivered on the IED Connectivity
package DVD as part of the product delivery.
The latest versions of the connection diagrams can be
downloaded from http://www.abb.com/substationautomation.
Connection diagrams for Customized products
Connection diagram, 670 series 2.0
1MRK002801-AE
Connection diagrams for Configured products
Connection diagram, RET670 2.0, A10 1MRK002803-TF
Connection diagram, RET670 2.0, A30 1MRK002803-TA
Connection diagram, RET670 2.0, B30 1MRK002803-TB
Connection diagram, RET670 2.0, A40 1MRK002803-TC
Connection diagram, RET670 2.0, B40
1MRK002803-TD
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 43

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
