ABB RET670 Product Guide

Communication
IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
Station communication
LONSPA, SPA SPA communication protocol 1 1 1 1 1 1 1
ADE LON communication protocol 1 1 1 1 1 1 1
HORZCOMM Network variables via LON 1 1 1 1 1 1 1
PROTOCOL Operation selection between
SPA and IEC 60870-5-103 for
SLM
1 1 1 1 1 1 1
RS485PROT Operation selection for RS485 1 1 1 1 1 1 1
RS485GEN RS485 1 1 1 1 1 1 1
DNPGEN DNP3.0 communication general
protocol
1 1 1 1 1 1 1
DNPGENTCP DNP3.0 communication general
TCP protocol
1 1 1 1 1 1 1
CHSERRS485 DNP3.0 for EIA-485
communication protocol
1 1 1 1 1 1 1
CH1TCP,
CH2TCP,
CH3TCP,
CH4TCP
DNP3.0 for TCP/IP
communication protocol
1 1 1 1 1 1 1
CHSEROPT DNP3.0 for TCP/IP and EIA-485
communication protocol
1 1 1 1 1 1 1
MST1TCP,
MST2TCP,
MST3TCP,
MST4TCP
DNP3.0 for serial
communication protocol
1 1 1 1 1 1 1
DNPFREC DNP3.0 fault records for TCP/IP
and EIA-485 communication
protocol
1 1 1 1 1 1 1
IEC61850-8-1 Parameter setting function for
IEC 61850
1 1 1 1 1 1 1
GOOSEINTLKRC
V
Horizontal communication via
GOOSE for interlocking
59 59 59 59 59 59 59
GOOSEBINRCV Goose binary receive 16 16 16 16 16 16 16
GOOSEDPRCV GOOSE function block to
receive a double point value
64 64 64 64 64 64 64
GOOSEINTRCV GOOSE function block to
receive an integer value
32 32 32 32 32 32 32
GOOSEMVRCV GOOSE function block to
receive a measurand value
60 60 60 60 60 60 60
GOOSESPRCV GOOSE function block to
receive a single point value
64 64 64 64 64 64 64
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
ABB 19

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
