ABB RET670 Product Guide

IEC 61850 ANSI Function description Transformer
RET670
RET670 (A10) RET670 (A30)
RET670 (B30)
RET670 (A40)
RET670 (B40)
RET670 (A25)
GOOSEVCTRCO
NF
GOOSE VCTR configuration for
send and receive
1 1 1 1 1 1 1
VCTRSEND Horizontal communication via
GOOSE for VCTR
1 1 1 1 1 1 1
GOOSEVCTRRC
V
Horizontal communication via
GOOSE for VCTR
7 7 7 7 7 7 7
MULTICMDRCV,
MULTICMDSND
Multiple command and transmit 60/10 60/10 60/10 60/10 60/10 60/10 60/10
FRONT, LANABI,
LANAB, LANCDI,
LANCD
Ethernet configuration of links 1 1 1 1 1 1 1
GATEWAY Ethernet configuration of link
one
1 1 1 1 1 1 1
OPTICAL103 IEC 60870-5-103 Optical serial
communication
1 1 1 1 1 1 1
RS485103 IEC 60870-5-103 serial
communication for RS485
1 1 1 1 1 1 1
AGSAL Generic security application
component
1 1 1 1 1 1 1
LD0LLN0 IEC 61850 LD0 LLN0 1 1 1 1 1 1 1
SYSLLN0 IEC 61850 SYS LLN0 1 1 1 1 1 1 1
LPHD Physical device information 1 1 1 1 1 1 1
PCMACCS IED Configuration Protocol 1 1 1 1 1 1 1
SECALARM Component for mapping
security events on protocols
such as DNP3 and IEC103
1 1 1 1 1 1 1
FSTACCS Field service tool access via
SPA protocol over ethernet
communication
1 1 1 1 1 1 1
ACTIVLOG Activity logging parameters 1 1 1 1 1 1 1
ALTRK Service Tracking 1 1 1 1 1 1 1
SINGLELCCH Single ethernet port link status 1 1 1 1 1 1 1
PRPSTATUS Dual ethernet port link status 1 1 1 1 1 1 1
Process bus communication
IEC 61850-9-2
1)
PRP IEC 62439-3 parallel
redundancy protocol (only in
F00)
0-1 1-P03 1-P03 1-P03 1-P03 1-P03 1-P03
Remote communication
Binary signal transfer receive/
transmit
6/36 6/36 6/36 6/36 6/36 6/36 6/36
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
20 ABB

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
