IEC 61850 ANSI Function description Transformer

RET670

RET670 (A10)

RET670 (A30)

RET670 (B30)

RET670 (A40)

RET670 (B40)

RET670 (A25)

ZMFPDIS 21 High speed distance protection 0–1

ZMFCPDIS 21 High speed distance protection

for series compensated lines

0–1

ZMRPSB 68 Power swing detection 0-1 1-B12

1-B13

1-B12

1-B13

1-B12

1-B13

1-B12

1-B13

PSLPSCH Power swing logic 0-1

PSPPPAM 78 Pole slip/out-of-step protection 0-1

OOSPPAM 78 Out-of-step protection 0–1

PPLPHIZ Phase preference logic 0-1

ZGVPDIS 21 Underimpedance for generators

and transformers

0–1 1-B14 1-B14 1-B14 1-B14

Transformer protection RET670 2.0

1MRK 504 141-BEN C

Product version: 2.0

12 ABB
