ABB RET670 Product Guide

Engineering manual, 670 series IEC Quantity: 1MRK 511 308-UEN
ANSI Quantity: 1MRK 511 308-UUS
Cyber security guideline IEC Quantity: 1MRK 511 309-UEN
Reference information
For our reference and statistics we would be pleased to be provided with the following application data:
Country: End user:
Station name: Voltage level: kV
Related documents
Documents related to RET670 Identify number
Application manual 1MRK 504 138-UEN
Commissioning manual 1MRK 504 140-UEN
Product guide 1MRK 504 141-BEN
Technical manual 1MRK 504 139-UEN
Type test certificate 1MRK 504 141-TEN
670 series manuals Identify number
Operation manual 1MRK 500 118-UEN
Engineering manual 1MRK 511 308-UEN
Installation manual 1MRK 514 019-UEN
Communication protocol manual,
IEC 60870-5-103
1MRK 511 304-UEN
Communication protocol manual,
IEC 61850 Edition 1
1MRK 511 302-UEN
Communication protocol manual,
IEC 61850 Edition 2
1MRK 511 303-UEN
Communication protocol manual,
LON
1MRK 511 305-UEN
Communication protocol manual,
SPA
1MRK 511 306-UEN
Accessories guide 1MRK 514 012-BEN
Cyber security deployment
guideline
1MRK 511 309-UEN
Connection and Installation
components
1MRK 513 003-BEN
Test system, COMBITEST 1MRK 512 001-BEN
Transformer protection RET670 2.0
1MRK 504 141-BEN C
Product version: 2.0
124 ABB

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
