12
LVD SCSIDE Bridge Manual
2. AEC-7726H/Q
l CN1 --- 68-pin female SCSI connector.
l CN2 --- 40-pin female IDE connector.
l CN3 --- 4-pin power connector.
l JP1 --- Refer to Figure 3-18 on page 34.
CN2
Figure 2-2a
Figure 2-2b
JP1 CN1
CN3
Top
