LVD SCSIDE Bridge Manual
2.3.3 Outlines
1. AEC-7722
l CN1--- 68-pin female SCSI connector.
l CN2 --- 40-pin female IDE connector.
l CN3 --- 4-pin power connector.
l JP1 --- Refer to Figure 3-16 on page 33.
l JP2 --- Refer to Figure 3-17 on page 33.
CN1 JP1
JP2 CN2
Figure 2-1
left CN3
