AccuEnergy Acuvim II series User Manual

4
1.2 Areas of Application

Power Distribution Automation

Electric Switch Gear and Control Panels

Industry Automation

Building Automation

Energy Management Systems

Marine Applications

Renewable Energy
1.3 Functionality
Multifunction
Acuvim II meters provide powerful data collecting and processing functions. In
additon to measuring various parameters, the meter is able to perform demand
metering, harmonic analysis, max/min statistic recording, over/under limit
alarming, energy accumulating and data logging.
High Accuracy
Accuracy of Voltage and Current is 0.2%, True-RMS.
Accuracy of Power and Energy is 0.2%, while monitoring all four quadrants.
Compact and Easy to Install
This meter can be installed into a standard ANSI C39.1 (4” Round) or an IEC
92mm DIN (Square) cut out. With the 51mm depth after mounting, the Acuvim
II series meter can be installed in a small cabinet. Mounting clips are used for
easy installation and removal.
Easy to Use
All metering data and setting parameters can be accessed by using the front
panel keys or via the communication port. Setting parameters are stored in the
EEPROM so that content will be preserved when the meter is powered o.
