116

DI4DI3DI2DI1

DI5 DI6 DIC RO1 RO2 ROC V+ V–

Digital Input

VDC

Relay Output

press the IO module lightly, so linking is established.

2. Tighten the installation screws.

3. Install other IO modules the same way.

Note: 1. Install IO Modules carefully to avoid damage;

2. Under no circumstances should any installation be done with the meter

powered on. Failure to do so may result in injury or death.

Fig 5-2 Installation of IO modules

5.1.5 Wiring of IO Modules

Terminal strips of AXM-IO1 module

Fig 5-3 Terminal strips of AXM-IO1 module
