AccuEnergy Acuvim II series User Manual

7
Category Item Parameters
Acuvim
II
Acuvim
IIR
Acuvim
IIE
Acuvim
IIW
Others
Communication
RS485 Port,Half
Duplex, Optical
Isolated
Modbus-RTU/DNP3.0 Protocol
Time Real Time Clock Year, Month, Date, Hour, Minute, Second
400Hz type
Only support full-wave energy,support
2
nd
~ 15
th
individual harmonics.
Option
Module
I/O Option
Switch Status (DI) Digital Input (Wet)
Power Supply for DI 24 Vdc
Relay Output (RO) NO, Form A
Digital Output (DO) Photo-MOS
Pulse Output (PO) By using DO
Analog Input (AI) 0(4)~20mA, 0(1)~5V
Analog Output (AO) 0(4)~20mA, 0(1)~5V
Communication
Ethernet
Modbus-TCP, HTTP , SNMP, SMTP,
SNTP
Probus-DP Probus-DP/V0
The second way
RS485 Module
Modbus-RTU Protocol
BACnet IP or MS/TP
Function; Option; Blank NA
