Category Item Parameters
Acuvim
II
Acuvim
IIR
Acuvim
IIE
Acuvim
IIW
Monitoring
Waveform
Capture If 400Hz
type,there is no this
function
voltage and
current Waveform
Trigger, Manual, DI change, Sag/Dips,
Swell, Over Current
Power Quality
Voltage
Unbalance Factor
U_unbl
Current
Unbalance Factor
I_unbl
Voltage THD THD_V1,THD_V2,THD_V3, THD_Vavg
Current THD THD_I1, THD_I2, THD_I, THD_Iavg
Individual Harmonics
Harmonics 2
nd
to 63
st
If 400Hz,Harmonics 2
nd
to 15
st
Voltage Crest Factor Crest Factor
TIF THFF
Current K factor K Factor
Statistics
MAX with Time
Stamp MIN with Time
Stamp
Each phase of V & l;Total of P, Q, S, PF &
F;Demad of P,Q & S;Each phase THD of V
& I;Unbalnce factor of V & I
Others
Alarm
Over/Under Limit
Alarm
V,I,P,Q,S,PF,V_THD & I_THD each phase
and total or average; Unbalance factor
of V & I;load type;Analog Input of each
channel
Power Quality Event
Logging
If 400Hz type,there
is no this function
SAG/DIPS,SWELL Voltage
Data Logging
Data Logging 1
Data Logging 2
Data Logging 3
F, V1/2/3/lnavg, V12/23/13/lavg, I1/2/3/
n/avg, P1/2/3/sum, Q1/2/3/sum, S1/2/3/
sum, PF1/2/3, PF, U_unbl, I_unbl, Load
Type, Ep_imp, Ep_exp, Ep_total, Ep_
net, Eq_imp, Eq_exp, Eq_total, Eq_net,
Es, THD_V1/2/3/avg, THD_I1/2/3/avg,
Harmonics 2
nd
to 63
rd
, Crest Factor, THFF,
K Factor, sequence and phase angles,
DI counter, AI, AO, Dmd P/Q/S, Dmd
I1/2/3Epa_imp; Epa_exp; Epb_imp; Epb_
exp; Epc_imp; Epc_exp;Eqa_imp; Eqa_
exp; Eqb_imp; Eqb_exp; Eqc_imp; Eqc_
exp; Esa; Esb; Esc
Onboard
Memory Size
Memory Bytes — 8MB 8MB 16MB
