AccuEnergy Acuvim II series User Manual

12
The installation method is introduced in this chapter. Please read this chapter
carefully before beginning installation.
2.1 Appearance and Dimensions
H P E V / A
Multifunction Power Meter
96.00 (3.800)
96.00 (3.800)



Gasket
91.00 (3.583)
35.90
12.8
(0.504)
(1.413)
14.00
(0.551)
35.90

91.00 (3.583)
38.00 (1.496)
7.60 (0.300)
(1.413)
50.70 (1.996)
91.00 (3.583)
35.90
(1.413)
50.70 (1.996)

Front View of the Display Meter
and Remote Display Unit
Gasket
Side View of the
Display Meter
Side View of the
Remote Display Unit
Side View of the
DIN rail Meter
12.8
(0.504)
96.00 (3.800)
