Table 5-29
Query
Frame Bytes Caption
Byte1 FAH
Byte2 10H
Byte3 starting address high byte
Byte4 starting address low byte
Byte5 quantity of registers high byte
Byte6 quantity of registers low byte
Byte7 byte count
Byte8 register value 1 high byte
Byte9 register value 1 low byte
Byte10 register value 2 high byte
Byte11 register value 2 low byte
...... ......
Byte32 0
“Quantity of registers” indicates how many words will be written.
“Byte count” indicates how many bytes will be written. If “quantity of register” is N,
then “byte count” is (N×2).
It is important to note: the response has a 16-word frame, so the maximum
"quantiy of registers" should be less than 13. Otherwise it will return an error
result.
Response
The normal response returns the function code, starting address, and quantity
of registers written.
