AccuEnergy Acuvim II series User Manual

244
Address Parameter Default Range
Data
type
Property
1012H Current I1 direction 0
0: Positive
1: Negative
word R/W
1013H Current I2 direction 0
0: Positive
1: Negative
word R/W
1014H Current I3 direction 0
0: Positive
1: Negative
word R/W
1015H VAR/PF convention 0 0: IEC, 1: IEEE word R/W
1016H Energy clear 0 Only 1 works word R/W
1017H Energy calculating mode 1
0: fundamental
1: full-wave
word R/W
1018H
Reactive power measuring
mode
0 0: real, 1: general word R/W
1019H Energy display mode 0 0: primary, 1: secondary word R/W
101AH Ethernet module reset 0
0: none, 1: reset,
2: load default and reset
word R/W
101BH SOE enable 0
0: none; 1: AXM-IO11;
2: AXM-IO21; 3: AXM-IO31;
4: AXM-IO12; 5: AXM-IO22;
6: AXM-IO32;
word R/W
101CH Pulse counter clear 0
0:none; 1:AXM-IO11;
2:AXM-IO21; 3:AXM-IO31;
4:AXM-IO12; 5:AXM-IO22;
6:AXM-IO32;
word R/W
101DH Basic parameter mode 0 0:secondary; 1:primary word R/W
Note:1) when 0FFEH is 0, rst communication protocol is set to MODBUS, while
0FFEH is 1, rst communication protocol is DNP3.0. At this time, special DNP3.0
software is needed, and normal software will be invalid.
2)100AH, 100BH setting method:1000 * 3600 / (U * I * n * pulse constant) = pulse
period (S), pulse period calculated by the pulse constant must be greater than
the pulse width (20ms ~ 1000ms) of IO module DO setting, Wherein n is applied
