AccuEnergy Acuvim II series User Manual

243
Table 6-15
Address Parameter Default Range
Data
type
Property
0FFDH Frequency 0
0 : 50Hz 1 : 60Hz
2: 400Hz
Word R/W
0FFEH
First communication
Protocol
0
0:MODBUS Protocol
1:DNP3.0 Protocol
Word R/W
0FFFH Parity Setting1 3
0: EVEN 1: odd 2:NON2
3:NON1
word R/W
1000H Password 0 0~9999 word R/W
1001H Communication address 1
1~247(MODBUS)
0~65534(DNP3.0)
word R/W
1002H Baud rate 19200 1200~38400 word R/W
1003H Voltage input wiring type 0
0:3LN,1:2LN,2:2LL,3:3LL
4:1LL
word R/W
1004H Current input wiring type 0 0:3CT,1:1CT,2:2CT word R/W
1005H PT1 (High 16 bit) 0
50.0~500000.0
word R/W
1006H PT1 (Low 16 bit) 220.0 word R/W
1007H PT2 220.0 50.0~400.0 word R/W
1008H CT1 5 1~50000 word R/W
1009H CT2 5 1,5,333,80,100,200 word R/W
100AH kWh pulse constant 1
1~60000(Setting
method,see Remarks)
word R/W
100BH kvarh pulse constant 1
1~60000(Setting
method,see Remarks)
word R/W
100CH LCD backlight time 1 0~120 word R/W
100DH Demand slid window time 15 1~30 word R/W
100EH Demand calculating mode 1
1:sliding window
2:thermal
word R/W
100FH Clear demand memory 0 Only 1 works word R/W
1010H Max/Min clear 55H Only 0AH works word R/W
1011H Run time clear 0 Only 1 works word R/W
