refer to F7, F8, and F9 for more details about the relationship between numerical
value in the register and the real physical value.
Table 6-32
Address Parameter Code Range Data type Property
4048H~4049H Energy IMP F4/F7 0~999999999 dword R/W
404AH~404BH Energy EXP F4/F7 0~999999999 dword R/W
404CH~404DH Reactive energy IMP F5/F8 0~999999999 dword R/W
404EH~404FH Reactive energy EXP F5/F8 0~999999999 dword R/W
4050H~4051H Energy TOTAL F4/F7 0~999999999 dword R/W
4052H~4053H Energy NET F4/F7
-999999999~
999999999
dword R/W
4054H~4055H Reactive energy TOTAL F5/F8 0~999999999 dword R/W
4056H~4057H Reactive energy NET F5/F8
-999999999~
999999999
dword R/W
4058H~4059H Apparent energy F6/F9 0~999999999 dword R/W
4620H~4621H Phase A Energy IMP F4/F7 0-999999999 dword R/W
4622H~4623H Phase A Energy EXP F4/F7 0-999999999 dword R/W
4624H~4625H Phase B Energy IMP F4/F7 0-999999999 dword R/W
4626H~4627H Phase B Energy EXP F4/F7 0-999999999 dword R/W
4628H~4629H Phase C Energy IMP F4/F7 0-999999999 dword R/W
462AH~462BH Phase C Energy EXP F4/F7 0-999999999 dword R/W
462CH~462DH
Phase A Reactive energy
IMP
F5/F8 0-999999999 dword R/W
462EH~462FH
Phase A Reactive energy
EXP
F5/F8 0-999999999 dword R/W
4630H~4631H
Phase B Reactive energy
IMP
F5/F8 0-999999999 dword R/W
4632H~4633H
Phase B Reactive energy
EXP
F5/F8 0-999999999 dword R/W
4634H~4635H
Phase C Reactive energy
IMP
F5/F8 0-999999999 dword R/W
4636H~4637H
Phase C Reactive energy
EXP
F5/F8 0-999999999 dword R/W
4638H~4639H Phase A Apparent energy F6/F9 0-999999999 dword R/W
