AccuEnergy Acuvim II series User Manual

264
Table 6-33
Address Parameter Code Range
Data type Property
The following are the THD of voltage and current
405AH THD_V1 of V1(V12) F18 >=0
word
R
405BH THD_V1 of V2(V31) F18 >=0
word
R
405CH THD_V1 of V3(V23) F18 >=0
word
R
405DH Average THD_V F18 >=0
word
R
405EH THD_I1 F18 >=0
word
R
405FH THD_I2 F18 >=0
word
R
4060H THD_I3 F18 >=0
word
R
4061H Average THD_I F18 >=0
word
R
Voltage Harmonics, even HD, odd HD, Crest Factor are shown as below
4062H~407FH
Harmonics of V1(V12)
(the 2
nd
to 31
st
)
F19 >=0
word
R
4500H~451FH
Harmonics of V1(V12)
(the 32
nd
to 63
rd
)
F19 >=0
word
R
4080H Odd HD of V1(V12) F20 >=0
word
R
4081H Even HD of V1(V12) F21 >=0
word
R
4082H Crest Factor of V1(V12) F22 0~65535
word
R
4083H THFF of V1(V12) F24 >=0
word
R
4084H~40A5H Parameters of V2(V31) Same as V1
word
R
4520H~453FH
Harmonics of V2(V31)
(the 32
nd
to 63
rd
)
F19 >=0
word
R
40A6H~40C7H Parameters of V3(V23) Same as V1
word
R
4540H~455FH
Harmonics of V3(V23)
(the 32
nd
to 63
rd
)
F19 >=0
word
R
Current Harmonics, even HD, odd HD, K factor are shown as below
40C8H~40E5H
Harmonics of I1
(the 2
nd
to 31
st
)
F19 >=0
word
R
4560H~457FH
Harmonics of I1
(the 32
nd
to 63
rd
)
F19 >=0
word
R
40E6H Odd HD of I1 F20 >=0
word
R
