Page #273 background imageLoading...
Page #273 background image
265
Address Parameter Code Range
Data type Property
40E7H Even HD of I1 F21 >=0
word
R
40E8H K Factor of I1 F23 0~65535
word
R
40E9H~4109H Parameters of I2 Same as I1
word
R
4580H~459FH
Harmonics of I2
(the 32
nd
to 63
rd
)
F19 >=0
word
R
410AH~412AH Parameters of I3 Same as I1
word
R
45A0H~45BFH
Harmonics of I3
(the 32
nd
to 63
rd
)
F19 >=0
word
R
Note:
When selecting 400Hz type, harmonics support 2
nd
~ 15
th
;
MAX/MIN records
MAX/MIN value and time stamp. Function code: 03H for reading.
Table 6-34
Address Parameter Code Range Data type Property
4136H MAX of V1 F11 -32768~32767 int R
4137H~413CH
Time stamp: yyyy:mm:
dd:hh:mm:ss
F3 time int R
413DH MAX of V2 F11 -32768~32767 int R
413EH~4143H
Time stamp: yyyy:mm:
dd:hh:mm:ss
F3 time int R
4144H MAX of V3 F11 -32768~32767 int R
4145H~414AH
Time stamp: yyyy:mm:
dd:hh:mm:ss
F3 time int R
414BH MAX of V12 F11 -32768~32767 int R
414CH~4151H
Time stamp: yyyy:mm:
dd:hh:mm:ss
F3 time int R
4152H MAX of V23 F11 -32768~32767 int R
4153H~4158H
Time stamp: yyyy:mm:
dd:hh:mm:ss
F3 time int R
4159H MAX of V31 F11 -32768~32767 int R
