Note: The MAX and MIN Frequency value should use word data type(0~65535).

Sequence component

U1 (U12), I1 are consisting of real part and complex part. They have positive

sequence, negative sequence and zero sequence. Data type is “int”. Function

code: 03H for reading.

Table 6-35

Address Parameter Code Range

Data

type

Property

4294H positive sequence real part of UA F11 -32768~32767 int R

4295H positive sequence complex part of UA F11 -32768~32767 int R

4296H negative sequence real part of UA F11 -32768~32767 int R

4297H negative sequence complex part of UA F11 -32768~32767 int R

4298H zero sequence real part of UA F11 -32768~32767 int R

4299H zero sequence complex part of UA F11 -32768~32767 int R

429AH positive sequence real part of IA F12 -32768~32767 int R

429BH positive sequence complex part of IA F12 -32768~32767 int R

429CH negative sequence real part of IA F12 -32768~32767 int R

429DH negative sequence complex part of IA F12 -32768~32767 int R

429EH zero sequence real part of IA F12 -32768~32767 int R

429FH zero sequence complex part of IA F12 -32768~32767 int R

Phase angle

All voltage and current’s phase angles corresponding to V1 (V12) are stored

here. You can find out the phase sequence according to them. Data type is

“word”. Function code: 03H for reading.

Table 6-36

Address Parameter Code Range Data type Property

42A0H

phase angle of V2 to V1 V1/

V2(3$4)

phase angle of V23 to V12

V12/V23(3$3)

F25 0~3600 word R
