272
Table 6-39
Address Parameter Code Range Data type Property
4385H AI1 sampling value F1 0~4095 word R
4386H AI2 sampling value F1 0~4095 word R
4387H AI3 sampling value F1 0~4095 word R
4388H AI4 sampling value F1 0~4095 word R
AO output
The output of AO is the actual value of output. There are 2 output options for
AO - V or mA. Over/under limit or Data type is “oat”. Function code: 03H for
reading. Please refer to Chapter 5 Extended Modules for more details.
Table 6-40
Address Parameter Code Range Data type Property
4389H - 438AH Value of A01 F1 oat R
438BH - 438CH Value of A02 F1 oat R
438DH - 438EH Value of A03 F1 oat R
438FH - 4390H Value of A04 F1 oat R
SOE Records
There are 20 groups of records with the same format. Function code: 03H for
reading. Before gathering SOE records, the selected I/O module must be SOE
enabled. If the SOE enabled I/O module is not connected, SOE record logs will
not be collected. Please refer to Chapter 5 Extended Modules for more details.
Table 6-41
Address Parameter Code Range Data type Property
4399H~439FH
First group: time stamp:
yyyy:mm:dd:hh:mm:ss:ms
F3 word R
43A0H First group: DI status F1 word R
43A1H~4438H 2
nd
to 20
th
group word R
