AccuEnergy Acuvim II series User Manual

273
4439H I/O module of SOE F1
0:none;
1:AXM-IO11;
2:AXM-IO21;
3:AXM-IO31;
4:AXM-IO12;
5:AXM-IO22;
6:AXM-IO32
word R
Current demand
Include real-time current demand, the maximum current demand and time of
occurance. Function code: 03H for reading.
Table 6-42
Address Parameter Code Range Data type Property
4600H-4601H Phase A current demand F1 I=Rx×(CT1/CT2) oat R
4602H-4603H Phase B current demand F1 I=Rx×(CT1/CT2) oat R
4604H-4605H Phase C current demand F1 I=Rx×(CT1/CT2) oat R
4606H
Max of Phase A current
demand
F12 -32768~32767 int R
4607-460CH
Time stamp:
yyyy:mm:dd:hh:mm:ss
F3 Time int
R
460DH
Max of Phase B current
demand
F12 -32768~32767 int R
460E-4613H
Time stamp:
yyyy:mm:dd:hh:mm:ss
F3 Time int
R
4614H
Max of Phase C current
demand
F12 -32768~32767 int R
4615-461AH
Time stamp:
yyyy:mm:dd:hh:mm:ss
F3 Time int
R
4F02H MESH Status
0:unnormal or not
connect ;
0xaa: normal
uint16 R
4F03H-4F0AH MESH MAC address
16 ASCII(from high byte
to low byte)
uint16 R
4F0BH-4F14H MESH identier
20ASCII (form high byte
to low byte)
uint16 R
