AccuEnergy Acuvim II series User Manual

274
DI Status
Current DI status, if related I/O module isn’t connected, the DI status will be set
to 0. Function code: 02H for reading.
Table 6-43
Address Parameter Range Data type
AXM-IO11
0000H DI1 1=ON,0=OFF bit
0001H DI2 1=ON,0=OFF bit
0002H DI3 1=ON,0=OFF bit
0003H DI4 1=ON,0=OFF bit
0004H DI5 1=ON,0=OFF bit
0005H DI6 1=ON,0=OFF bit
AXM-IO21
0006H DI7 1=ON,0=OFF bit
0007H DI8 1=ON,0=OFF bit
0008H DI9 1=ON,0=OFF bit
0009H DI10 1=ON,0=OFF bit
AXM-IO31
000AH DI11 1=ON,0=OFF bit
000BH DI12 1=ON,0=OFF bit
000CH DI13 1=ON,0=OFF bit
000DH DI14 1=ON,0=OFF bit
AXM-IO12
000EH DI15 1=ON,0=OFF bit
000FH DI16 1=ON,0=OFF bit
0010H DI17 1=ON,0=OFF bit
0011H DI18 1=ON,0=OFF bit
0012H DI19 1=ON,0=OFF bit
0013H DI20 1=ON,0=OFF bit
AXM-IO22
0014H DI21 1=ON,0=OFF bit
0015H DI22 1=ON,0=OFF bit
