319
5) Data Link Layer Conrmation
Supported
6) Application Layer Conrmation
Supported
7) Application Layer Function
Request
Supported 0X01, Read
Qualier, 0X00, 0X01, 0X06.
Response
Supported 129, Read Response
Qualier, 0X00
Supported Error Internal Indicator Response
8) DATA OBJECT LIBRARY
a) ANALOG INPUT OBJECT 30
Variation: 3, 32-BIT ANALOG INPUT WITHOUT FLAG
Variation: 4, 16-BIT ANALOG INPUT WITHOUT FLAG
Variation 5, 32-BIT FLOAT WITH FLAG
b) COUNTER OBJECT DEFINITIONS 20
Variation: 5, 32-BIT COUNTER WITHOUT FLAG
c) ALTERNATE NUMERIC OBJECT 100
