Table 6-59
Object Point Variation Name Format Range Multiplier Units Descriptor
100 0 1 Freq_rms Float 1.0 Hz Frequency
100 1 1 Ua_rms Float 1.0 V Voltage A
100 2 1 Ub_rms Float 1.0 V Voltage B
100 3 1 Uc_rms Float 1.0 V Voltage C
100 4 1 Uvag_rms Float 1.0 V Phrase Voltage Avg
100 5 1 Uab_rms Float 1.0 V Voltage A-B
100 6 1 Ubc_rms Float 1.0 V Voltage B-C
100 7 1 Uca_rms Float 1.0 V Voltage C-A
100 8 1 Ulag_rms Float 1.0 A Line Voltage Avg
100 9 1 Ia_rms Float 1.0 A Current A
100 10 1 Ib_rms Float 1.0 A Current B
100 11 1 Ic_rms Float 1.0 A Current C
100 12 1 Ivag_rms Float 1.0 A Current Average
100 13 1 In_rms Float 1.0 A Neutral Current
100 14 1 Pa_rms Float 1.0 W Pa
100 15 1 Pb_rms Float 1.0 W Pb
100 16 1 Pc_rms Float 1.0 W Pc
100 17 1 P_rms Float 1.0 W Total Active Power
100 18 1 Qa_rms Float 1.0 var Qa
100 19 1 Qb_rms Float 1.0 var Qb
100 20 1 Qc_rms Float 1.0 var Qc
100 21 1 Q_rms Float 1.0 var
Total Reactive
Power
100 22 1 Sa_rms Float 1.0 VA Sa
100 23 1 Sb_rms Float 1.0 VA Sb
100 24 1 Sc_rms Float 1.0 VA Sc
100 25 1 S_rms Float 1.0 VA
Total Apparent
Power
100 26 1 PFa_rms Float 1.0 None PFa
100 27 1 PFb_rms Float 1.0 None PFb
