AccuEnergy Acuvim II series User Manual

322
Object Point Variation Name Format Range Multiplier Units Descriptor
100 28 1 PFc_rms Float 1.0 None PFc
100 29 1 PF_rms Float 1.0 None Total Power Factor
100 30 1 Unbl_u2 Float 1.0 None Voltage Imbalance
100 31 1 Unbl_i2 Float 1.0 None Current Imbalance
100 32 1 Rlc_val Float 1.0 None
Load
Characteristics
100 33 1 P_dema Float 1.0 W P Demand
100 34 1 Q_dema Float 1.0 var Q Demand
100 35 1 S_dema Float 1.0 VA S Demand
100 36 1 Ia_Demand Float 1.0 A Ia Demand
100 37 1 Ib_Demand Float 1.0 A Ib Demand
100 38 1 Ic_Demand Float 1.0 A Ic Demand
Table 6-60
Object Point Variation Name Format Range Multiplier Units Descriptor
20 0 5
Active_
Energy_IMP
UINT32 0~999999999 0.1/0.001 W/hr
Active_ Energy_
IMP
20 1 5
Active_
Energy_EXP
UINT32 0~999999999 0.1/0.001 W/hr
Active_ Energy_
EXP
20 2 5
Reactive_
Energy_IMP
UINT32 0~999999999 0.1/0.001 var/hr
Reactive_
Energy_IMP
20 3 5
Reactive_
Energy_EXP
UINT32 0~999999999 0.1/0.001 var/hr
Reactive_
Energy_EXP
20 4 5
Active_
Energy_
TOTAL
UINT32 0~999999999 0.1/0.001 W/hr
Active_ Energy_
TOTAL
20 5 5
Active_
Energy_NET
UINT32 0~999999999 0.1/0.001 W/hr
Active_ Energy_
NET
20 6 5
Reactive_
Energy_
TOTAL
UINT32 0~999999999 0.1/0.001 var/hr
Reactive_
Energy_TOTAL
