AccuEnergy Acuvim II series User Manual

323
Object Point Variation Name Format Range Multiplier Units Descriptor
20 7 5
Reactive_
Energy_NET
UINT32 0~999999999 0.1/0.001 var/hr
Reactive_
Energy_NET
20 8 5
Apprent_
Energy
UINT32 0~999999999 0.1/0.001 VA/hr Apprent_ Energy
20 9 5 DI1Counts UINT32 0~4294967259 1 None DI1Counts
20 10 5 DI2Counts UINT32 0~4294967259 1 None DI2Counts
20 11 5 DI3Counts UINT32 0~4294967259 1 None DI3Counts
20 12 5 DI4Counts UINT32 0~4294967259 1 None DI4Counts
20 13 5 DI5Counts UINT32 0~4294967259 1 None DI5Counts
20 14 5 DI6Counts UINT32 0~4294967259 1 None DI6Counts
20 15 5 DI7Counts UINT32 0~4294967259 1 None DI7Counts
20 16 5 DI8Counts UINT32 0-4294967259 1 None DI8Counts
20 17 5 DI9Counts UINT32 0~4294967259 1 None DI9Counts
20 18 5 DI10Counts UINT32 0~4294967259 1 None DI10Counts
20 19 5 DI11Counts UINT32 0~4294967259 1 None DI11Counts
20 20 5 DI12Counts UINT32 0~4294967259 1 None DI12Counts
20 21 5 DI13Counts UINT32 0~4294967259 1 None DI13Counts
20 22 5 DI14Counts UINT32 0~4294967259 1 None DI14Counts
20 23 5 DI15Counts UINT32 0~4294967259 1 None DI15Counts
20 24 5 DI16Counts UINT32 0~4294967259 1 None DI16Counts
20 25 5 DI17Counts UINT32 0~4294967259 1 None DI17Counts
20 26 5 DI18Counts UINT32 0~4294967259 1 None DI18Counts
20 27 5 DI19Counts UINT32 0~4294967259 1 None DI19Counts
20 28 5 DI20Counts UINT32 0~4294967259 1 None DI20Counts
20 29 5 DI21Counts UINT32 0~4294967259 1 None DI21Counts
20 30 5 DI22Counts UINT32 0~4294967259 1 None DI22Counts
20 31 5 DI23Counts UINT32 0~4294967259 1 None DI23Counts
20 32 5 DI24Counts UINT32 0~4294967259 1 None DI24Counts
20 33 5 DI25Counts UINT32 0~4294967259 1 None DI25Counts
20 34 5 DI26Counts UINT32 0~4294967259 1 None DI26Counts
20 35 5 DI27Counts UINT32 0~4294967259 1 None DI27Counts
20 36 5 DI28Counts UINT32 0~4294967259 1 None DI28Counts
