AccuEnergy Acuvim II series User Manual

324
Table 6-61
Object Point Variation Name Format Range Multiplier Units Descriptor
30 0 4 THD_V1 UINT16 0~10000 0.01 None THD_V1
30 1 4 THD_V2 UINT16 0~10000 0.01 None THD_V2
30 2 4 THD_V3 UINT16 0~10000 0.01 None THD_V3
30 3 4 THD_V UINT16 0~10000 0.01 None THD_V
30 4 4 THD_I1 UINT16 0~10000 0.01 None THD_I1
30 5 4 THD_I2 UINT16 0~10000 0.01 None THD_I2
30 6 4 THD_I3 UINT16 0~10000 0.01 None THD_I3
30 7 4 THD_I UINT16 0~10000 0.01 None THD_I
Table 6-62
Object Point Variation Name Format Range Multiplier Units Descriptor
12 0 1
DNP_
MODBUS
None 1 1 None
Responds to Function
6 (Direct Operate-No
Ack) , Qualier Code
17x, Control Code 3,
Count 0, On 0 msec,
O 1 msec ONLY
12 1 1
Reset_
Energy_
Counters
None 1 1 None
Responds to Function
5 (Direct Operate)
Qualier Code 17x or
28x, Control Code 3,
Count 0, On 0 msec,
O 1 msec ONLY
12 2 1
Reset_
Demand_
Counters
None 1 1 None
Responds to Function
5 (Direct Operate)
Qualier Code 17x or
28x, Control Code 3,
Count 0, On 0 msec,
O 1 msec ONLY
