325
6.4.9 DNP3.0 Message Layout
The following table is the abbreviation and explain.
Table 6-63
DestL The destination address low byte
DestH The destination address high byte
SorcL The source address low byte
SorcH The source address high byte
CrcL The Cyclic Redundancy Checksum low byte
CrcH The Cyclic Redundancy Checksum high byte
x The transport layer data sequence num
y The application layer data sequence num
II1 The rst byte of Internal Indicator
II2 The second byte of Internal Indicator
Link Layer Frames:
Table 6-64
Reset Link:
Request 05 64 05 C0 DestL DestH SorcL SorcH CrcL CrcH
Response 05 64 05 00 SorcL SorcH DestL DestH CrcL CrcH
Reset User:
Request 05 64 05 C1 DestL DestH SorcL SorcH CrcL CrcH
Response 05 64 05 00 SorcL SorcH DestL DestH CrcL CrcH
Link Status:
Request 05 64 05 C9 DestL DestH SorcL SorcH CrcL CrcH
Response 05 64 05 00 SorcL SorcH DestL DestH CrcL CrcH
