Machine Maintenance Procedures 3-37
Make sure all cables and antennas are moved away from the device to avoid
damage during removal.
LCD Module Installation 0
1. Place the LCD Module on the base assembly. The LVDS cable and the antenna must
be placed above the LCD hinges. Refer to Figure 3-35.
2. Align LCD hinges with the hinge guides on the Base Assembly. Refer to Figure 3-35.
3. Install and secure three (3) screws (A) to LCD hinges. Refer to Figure 3-34.
4. Place the antenna (B) to the cable guides and secure it with the tape (C). Refer to
Figure 3-34.
5. Install Mainboard.
ID Size Quantity Screw Type
AM2.5*6 3
