Acer Aspire E1-431 - LCD Panel Removal

Machine Maintenance Procedures 3-45
LCD Panel Removal 0
Prerequisite:
Camera Module Removal
1. Remove the microphone (B) from its compartment on the LCD cover (Figure 3-44).
2. Remove the six (6) screws (A) from the LCD panel (Figure 3-44).
Figure 3-44. LCD Panel
3. Lift the LCD panel (C) from LCD cover (Figure 3-44).
CAUTION:
!
Make sure all cables are moved away from the device to avoid damage
during LCD Panel removal.
B
A
A
C
A
A
